| Specification | Value |
|---|---|
| Engine Brand | SATOSHI POWER |
| Power coverage from | 12-415KVA |
| Engine Type | 4 Cycle , PS6 Mitsu / Bosch A Style pump |
| Speed | 1500rpm / 1800rpm |
| Frequency | 50Hz/ 60Hz |
| Cooling System | Water-cooled |
| IP Protection / Insulation Class | IP23 , Class F / Class H |
| Alternator | Satoshi Power / Stamford....etc. |
| Controller | Deepesea / Style Japan Controller |
| ATS System | Option / Built-in |
| Genset Version | Opent type / Silent type / Super Silent type |
| Genset Series | STG-DSF |
| SERIES 50HZ 1500R.P.M | ||||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|
| Genset Version | Genset Performance | Engine Performance | Dimension(L*W*H) | Data Sheets | ||||||||
| Open Type Genset Model | Silent Type Genset Model | Standby Power | Prime Power | Engine Model | Net Power (KW) | Cyl.-Bore*Stroke (mm) | Displacement (L) | Open type (mm) | Silent Type (mm) | - | ||
| kVA | kW | kVA | kW | |||||||||
| - | STG- 18DDSF | 18 | 14 | 16 | 12.8 | SDE4L-F17 | 17 | 4-85*100 | 2.27 | - | - | - |
| - | STG-22DSF | 22 | 18 | 20 | 16 | SDE4L-F21 | 21 | 4-90*100 | 2.54 | - | - | - |
| - | STG-30DSF | 30 | 24 | 27.5 | 22 | SDE4L-F26 | 26 | 4-90*100 | 2.54 | - | - | - |
| - | STG-35DSF | 35 | 28 | 30 | 24 | SDE4L-F29 | 29 | 4-90*100 | 2.54 | - | - | - |
| - | STG-40DSF | 40 | 32 | 35 | 28 | SDE4L-F33 | 33 | 4-102*118 | 3.86 | - | - | - |
| - | STG-45DSF | 45 | 36 | 40 | 32 | SED4L-F38 | 38 | 4-102*118 | 3.86 | - | - | - |
| - | STG-55DSF | 55 | 44 | 50 | 40 | SDE4L-F48 | 48 | 4-102*118 | 3.86 | - | - | - |
| - | STG-70DSF | 70 | 56 | 60 | 48 | SDE4L-F57 | 57 | 4-102*118 | 3.86 | - | - | - |
| - | STG-75DSF | 75 | 60 | 70 | 56 | SDE4L-F65 | 65 | 4-110*125 | 4.75 | - | - | - |
| - | STG-100DSF | 100 | 80 | 90 | 72 | SDE4L-F84 | 84 | 4-11*125 | 4.75 | - | - | - |
| - | STG-110DSDF | 110 | 88 | 100 | 800 | SDE6L-F96 | 96 | 6-110*115 | 6.55 | - | - | - |
| - | STG-135DSF | 135 | 108 | 125 | 80 | SDE6L-F125 | 125 | 6-110*125 | 7.13 | - | - | - |
| - | STG-165DSF | 165 | 132 | 150 | 100 | SDE6L-F140 | 140 | 6-110*125 | 7.13 | - | - | - |
| - | STG-200DSF | 200 | 160 | 185 | 120 | SDE6L-F176 | 176 | 6-110*135 | 7.70 | - | - | - |
| - | STG-250DSF | 250 | 200 | 225 | 150 | SDE6L-F205 | 205 | 6-112*145 | 8.57 | - | - | - |
| - | STG-275DSF | 275 | 220 | 250 | 180 | SDE6L-F227 | 227 | 6-112*145 | 8.57 | - | - | - |
| - | STG-300DSF | 300 | 240 | 275 | 220 | SDE6L-F287 | 287 | 6-123*155 | 11.04 | - | - | - |
| - | STG-330DSF | 330 | 264 | 300 | 240 | SDE6L-F287 | 287 | 6-123*155 | 11. 04 | - | - | - |
| - | STG-350DSF | 350 | 280 | 325 | 260 | SDE6L-F300 | 300 | 6-123*155 | 11.04 | - | - | - |
| - | STG-415DSF | 415 | 332 | 375 | 300 | SDE6L-F332 | 332 | 6-131*155 | 12.53 | - | - | - |
