| Specification | Value |
|---|---|
| Engine Brand | MITSUBISHI |
| Power coverage | 135-200KVA |
| Engine Type | Continuous , Mitsubishi Direct Injection , 4-Cycel, Diesel |
| Speed | 1500rpm |
| Frequency | 50Hertz |
| Cooling System | Water-cooled |
| Insulation Protection | IP23 |
| Insulation Grade | Class F/ H |
| Alternator | Taiyo / Satoshi / Stamford / Other..... |
| Controller | Japan Control / Deepsea / Woodward / Other..... |
| ATS Systerm | Optional |
| Genset Version | Open Configuration / Canopy Silent |
| Genset Series | STG-M |
| SERIES 50HZ 1500R.P.M | ||||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|
| Genset Version | Genset Performance | Engine Performance | Dimension(L*W*H) | Data Sheets | ||||||||
| Open Type Genset Model | Silent Type Genset Model | Standby Power | Prime Power | Engine Model | Net Power (kw) | Cyl.-Bore*sstroke (mm) | Displacement (L) | Open type (mm) | Silent Type (mm) | - | ||
| kVA | kW | kVA | kW | |||||||||
| STG-M150 | STG-M150S | 150 | 120 | 135 | 108 | 6D14T-ZL1 | 140 | 6L*118*115 | 7.4 | 2600*1000*1500 | 3300*1150*1800 | - |
| STG-M156 | STG-M165S | 165 | 132 | 150 | 120 | 6D14T-ZL1 | 140 | 6L-118*115 | 7.4 | 2600*1000*1500 | 3300*1150*1800 | - |
| STG-M175 | STG-M175S | 175 | 140 | 165 | 132 | 6D14T-ZL1 | 140 | 6L-130*130 | 7.4 | 2800*100*1650 | 3600*1250*1800 | - |
| STG-M200 | STG-M200S | 200 | 160 | 180 | 144 | 6D22T-ZL1 | 180 | 6L-130*150 | 11.1 | 2800*1150*1650 | 3600*1250*1850 | - |
